VLM100W-48 Constant Voltage LED Driver
Regular price
$48.00
Unit price
Unavailable
Description
Description
The ERP Power VLM100W48 is a 100W constant voltage LED driver providing 48V output for higher voltage LED strip and lighting systems.
-
Key Features
- 100W constant voltage driver
- 48V DC output
- High efficiency
- Ideal for long-run LED systems
Specifications
Specifications
| Attribute | Specification |
|---|---|
| Brand | ERP Power |
| Product Code | VLM100W48 |
| Input Voltage | 120–277VAC |
| Input Frequency | 50/60Hz |
| Max Output Power | 100W |
| Output Current Range | 2.1A |
| Output Voltage Range | 48VDC |
| Efficiency | Up to 90% |
| Power Factor | ≥0.95 |
| THD | <20% |
| Inrush Current | <40A |
| Operating Temperature | -20°C to +50°C |
| Case Temperature (Tc) | 90°C max |
| Output Protection | Short circuit, overload, thermal |
| Dimming Control | Non-Dimming |
| Dimming Range | Non-Dimming |
| Advanced Features | High voltage constant output |
| Enclosure Rating | IP20 |
| Dimensions | ~8.0" x 2.0" x 1.2" |
| Mounting Length | ~7.5" |
| Certifications & Compliance | UL, FCC, RoHS |
| Sound Rating | Class A |
| Warranty | 5 Years |
