OTI 190W 277-480 2750C 2DIM P6 DIM1
Description
Description
The eldoLED OTi 190W 2DIM P6 DIM-1 is a premium programmable constant current LED driver engineered for high-power lighting systems requiring precision, reliability, and smooth dimming performance. Designed for 277–480VAC input, this driver is ideal for large-scale commercial, industrial, and outdoor lighting applications.
Delivering up to 2750mA output current, this driver provides flexible configuration to match a wide range of LED loads. The driver features 0–10V (2DIM) dimming, utilizing a standard two-wire low-voltage control interface for consistent and reliable analog dimming performance.
With eldoLED’s industry-leading dimming technology, the OTi series ensures flicker-safe, smooth dimming down to low levels, making it suitable for applications where visual comfort and lighting quality are critical.
The P6 platform enables advanced programmability, allowing customization of output current, minimum dim level, and dimming curve to meet exact fixture and project requirements.
Key Features
- 190W constant current LED driver
- Wide input voltage: 277–480VAC
- Adjustable output current up to 2750mA
- 0–10V dimming (2DIM – 2-wire control input)
- Programmable via eldoLED tools (NFC or wired programming)
- Flicker-safe dimming for high visual comfort
- High efficiency and robust thermal performance
- Designed for commercial, industrial, and outdoor applications
Specifications
Specifications
| Attribute | Specification |
|---|---|
| Product Code | OTi 190W 277-480 2750C 2DIM P6 DIM-1 |
| Input Voltage | 277–480VAC |
| Input Frequency | 50/60 Hz |
| Max Output Power | 190W |
| Output Current Range | 700–2750mA (programmable) |
| Output Voltage Range | ~54–215VDC (auto-adjusting within power limits) |
| Efficiency | Up to ~94% |
| Power Factor | ≥ 0.95 |
| THD | ≤ 20% |
| Inrush Current | ~70A peak (typical, 230µs duration) |
| Operating Temperature | -40°C to +55°C (ambient) |
| Case Temperature (Tc) | Max 90°C |
| Dimming Control | 0–10V (2DIM, 2-wire analog input) |
| Dimming Range | 1% – 100% (typical, programmable low-end trim) |
| Enclosure Rating | IP66 (suitable for outdoor use) |
| Dimensions | ~13.3" L × 2.6" W × 1.6" H |
| Mounting Length | ~12.6" |
| Sound Rating | Class A |
| Warranty | 5-Year Limited Warranty |
