VLM60W-24 Constant Voltage LED Driver
Description
Description
The ERP Power VLM60W-24 is a compact, high-efficiency constant voltage LED driver engineered for architectural and commercial lighting applications where space, reliability, and performance are critical. Delivering a regulated 24 Vdc output with up to 60 W of power, this driver is ideal for low-voltage LED tape, linear lighting, and LED modules. Its wide 90–305 Vac input range and Class 2 output simplify specification across diverse installations while ensuring safe, code-compliant operation.
Designed for long-term durability, the VLM60W-24 features a rugged aluminum housing with silicone potting to enhance thermal performance and vibration resistance. With efficiency up to 91%, high power density, and a rated lifetime of 50,000 hours at maximum case temperature, this non-dimmable driver supports consistent, maintenance-free operation. The IP20-rated enclosure is suitable for dry and damp locations, making it a dependable solution for space-constrained luminaires and integrated lighting systems.
-
Regulated 24V Constant Voltage Output: Factory-programmed 24 Vdc output ensures stable performance for LED tape and modules.
-
Ultra-Compact High Power Density Design: Delivers up to 60 W in a small aluminum enclosure optimized for tight installations.
-
High Efficiency Performance: Up to 91% efficiency reduces energy loss and supports long-term reliability.
-
Class 2 Non-Dimmable Output: Simplifies system design while meeting safety and compliance requirements.
-
Long Lifetime and Rugged Construction: Silicone potting, thermal protection, and a 50,000-hour rating support demanding applications.
Specifications
Specifications
| Attribute | Specification |
|---|---|
| Brand / Series | ERP Power – VLM Series |
| Model | VLM60W-24 |
| Product Code | VLM60W-24 |
| Input Voltage | 90–305 Vac |
| Output Voltage | 24 Vdc, regulated |
| Output Current | 0.2–2.5 A |
| Maximum Output Power | 60 W |
| Output Type | Constant voltage, non-dimmable |
| Efficiency | Up to 91% |
| Power Factor | > 0.9 |
| Total Harmonic Distortion | < 20% |
| Start-Up Time | 300 ms typical |
| Protection Features | Over-voltage, short circuit, thermal shutdown |
| Surge Immunity | ANSI C62.41 Category A, 2.5 kV ring wave |
| Ambient Temperature Range | -20°C to +50°C |
| Maximum Case Temperature (Tc) | 90°C |
| Enclosure Rating | IP20 |
| Dimensions | 4.13 in × 1.02 in × 0.78 in |
| Weight | 113 g (4 oz) |
| Lifetime Rating | 50,000 hours at maximum case temperature |
| Certifications / Compliance | UL Listed Class P, UL8750 Class 2 output, FCC Part 15, ENERGY STAR compatible, DLC compatible, California Title 24, IEC61000 series, NEMA 410 |
