eldoLED ECOdrive 30D Constant-Current DMX LED Driver
Description
Description
The eldoLED ECOdrive 30D is a 30-Watt DMX-compatible LED driver designed for high-performance, flicker-free dimming. With four independent LED outputs, this driver allows precise control of color and brightness in both standalone and networked DMX applications. Its HydraDrive technology ensures smooth color fades and dimming to near-dark levels, making it ideal for architectural and entertainment lighting. Configurations such as DMX channel assignment, color, and dim values can be easily adjusted via the intuitive 3-button user interface with display. The driver also features NTC-based thermal management, high efficiency, and dynamic response tuning to match any content speed.
Specifications
Specifications
| Attribute | Specification |
|---|---|
| Driver Type | Constant Current |
| Number of LED Outputs | 4 (UL Class 2) |
| Max LED Output Power | 30W |
| Programmable LED Current Range | 200–1,050 mA |
| LED Output Type | Programmable in 50 mA steps via driver interface, programmable in 25 mA steps via DMX terminal and FluxTool |
| LED Output Voltage Range | 11–31 V (Vf LEDs < Vsup-1V) |
| Input Voltage (DC) | 12–32 V |
| Control Protocol | DMX |
| Control Channels | 4 |
| Dimensions (L×W×H) | 153 × 50 × 23 mm (6.02 × 1.97 × 0.91 in) |
| Weight | 128.5 g |
