OTI 85W UNV 2A3 1DIM DIM-1 J10

The eldoLED OPTOTRONIC OTi 85W UNV 2A3 1DIM DIM-1 J10 is a programmable constant current LED driver designed for high-performance commercial and architectural LED luminaires. Delivering up to 85W of power and a programmable output current range of 700–2300mA, it provides precise, flicker-free illumination for offices, retail spaces, and decorative lighting installations. Featuring 0–10V analog dimming with a 1–100% range, this driver enables smooth light adjustment while maintaining optimal energy efficiency and consistent lumen output. Built-in LED thermal protection ensures safe operation, making it ideal for demanding indoor environments.

With a factory default output of 1400mA, the OTi 85W driver is flexible enough for a wide range of fixtures. Its universal input voltage of 120–277V AC allows easy integration into commercial electrical systems, while the compact J-style design and 10.63" mounting center simplify installation. Certified UL Class 2 and rated for dry/damp locations, this driver delivers professional-grade performance, reliability, and long-term durability for architects, lighting designers, and contractors.

Key Features

• Programmable Output Current: Adjustable 700–2300mA in 1mA increments, factory default 1400mA for precise lighting control.

• 0–10V Analog Dimming: Smooth, flicker-free dimming from 1–100% for optimal light adjustment.

• High Output Power: Supports up to 85W, suitable for a wide variety of commercial and architectural LED luminaires.

• LED Thermal Protection: Prevents overheating to ensure safe and reliable operation.

• J-Style Compact Mounting: Easy installation with 10.63" mounting center, UL Class 2 certified, and rated for dry/damp locations.
