OTI 85W UNV 2A3 1DIM AUX DIM-1 J10
Description
Description
The eldoLED OPTOTRONIC OTI 85W UNV 2A3 1DIM AUX DIM-1 J10 is a high-performance programmable constant current LED driver designed for commercial, architectural, and industrial LED luminaires. Delivering up to 85W of power and a programmable output current range of 700–2300mA, it ensures precise, flicker-free illumination for offices, retail spaces, warehouses, and high-ceiling environments. With 0–10V analog dimming and a 1–100% dimming range, this driver allows smooth, energy-efficient light adjustment while maintaining consistent lumen output. Integrated LED thermal protection ensures safe operation, making it a reliable choice for demanding indoor and high-bay lighting applications.
Featuring a factory default output of 1400mA, the OTI 85W AUX driver supports flexible installation across a variety of fixtures. Its universal input voltage of 120–277V AC provides broad compatibility with commercial electrical systems, while the compact J-style design with a 10.63" mounting center simplifies installation. Certified UL Class 2 and rated for dry/damp locations, this driver delivers professional-grade performance, efficiency, and reliability, making it ideal for architects, lighting designers, and contractors.
Key Features
-
Programmable Output Current: Adjustable 700–2300mA in 1mA increments, factory default 1400mA for precise lighting control.
-
0–10V Analog Dimming: Smooth, flicker-free dimming from 1–100% for optimized illumination.
-
High Output Power: Supports up to 85W, suitable for commercial, architectural, and industrial LED fixtures.
-
LED Thermal Protection: Prevents overheating to ensure safe and reliable operation.
-
Auxiliary Output & J-Style Mounting: Provides additional control flexibility with easy installation in dry/damp locations.
Specifications
Specifications
| Attribute | Specification |
|---|---|
| Product Code | OTI 85W UNV 2A3 1DIM AUX DIM-1 J10 |
| Manufacturer Material Code | 57420/*2743W5 |
| Brand | Acuity eldoLED OPTOTRONIC |
| Driver Type | Constant-Current Programmable |
| Fixture Type | LED |
| Input Voltage | 120–277V AC |
| Max Output Power | 85W |
| Max Output Current | 2300mA |
| Factory Output Current | 1400mA |
| Output Current Programmable Range | 700–2300mA |
| Max Output Voltage | 55V |
| Output Voltage Range | 10–55V |
| Dimming | Analog 0–10V, 1–100% |
| Thermal Protection | Yes |
| AUX Output | Included |
| Location Rating | Dry/Damp |
| Dimensions | 16.73" L x 1.16" W x 1.00" H (Mounting Center 10.63") |
| UL Class | Class 2 |
| Features | Dimming Range 1–100%, AUX Output |
| Alternative Keywords | OTI851202772A3DIM1AUXJ10 |
| Warranty | 5-Year Manufacturer |
| Case Size | 10 |
