OTI 85W UNV 2A3 1DIM DIM-1 HI-BAY J10

The eldoLED OPTOTRONIC OTI 85W UNV 2A3 1DIM DIM-1 HI-BAY J10 is a high-performance programmable constant current LED driver designed for commercial, architectural, and high-bay LED luminaires. Delivering up to 85W of power with a programmable current range of 700–2300mA, it provides precise, flicker-free illumination for warehouses, gymnasiums, industrial spaces, and decorative lighting. Featuring 0–10V analog dimming with a 1–100% range, this driver ensures smooth light adjustment while maintaining energy efficiency and long-term lumen consistency. Built-in LED thermal protection safeguards the system against overheating, making it a reliable solution for demanding high-bay and indoor applications.

With a factory default output of 1400mA, the OTI 85W HI-BAY driver is versatile for a wide variety of fixtures. Its universal input voltage of 120–277V AC allows seamless integration into commercial electrical systems, while the compact J-style design with a 10.63" mounting center simplifies installation. Certified UL Class 2 and rated for dry/damp locations, this driver delivers professional-grade performance, energy efficiency, and reliability for architects, lighting designers, and contractors in high-ceiling environments.

Key Features

• Programmable Output Current: Adjustable 700–2300mA in 1mA increments, factory default 1400mA for precise lighting control.

• 0–10V Analog Dimming: Smooth, flicker-free dimming from 1–100% for optimal light adjustment.

• High Output Power: Supports up to 85W, suitable for high-bay and commercial LED luminaires.

• LED Thermal Protection: Prevents overheating to ensure safe, long-lasting operation.

• J-Style High-Bay Mounting: Easy installation with 10.63" mounting center, UL Class 2 certified, and rated for dry/damp locations.
