PKB85W-2300-55-TN 85 Watt Constant Current LED Driver
Regular price
$16.50
Unit price
Unavailable
Description
Description
The ERP Power PKB85W-2300-55-TN is a high-output 85W programmable constant current LED driver designed for demanding commercial and architectural lighting applications. With a wide programmable current range and 0-10V dimming, it provides maximum flexibility for fixture manufacturers and integrators.
Key Features
- 85W programmable LED driver
- Output current up to 2300mA
- 0-10V dimming control
- Wide output voltage range
- Ideal for high-power fixtures
- Compact design for integration
Specifications
Specifications
| Attribute | Specification |
|---|---|
| Brand | ERP |
| Product Code | PKB85W-2300-55-TN |
| Input Voltage | 120–277VAC |
| Input Frequency | 50/60Hz |
| Max Output Power | 85W |
| Output Current Range | 500–2300mA (programmable) |
| Output Voltage Range | 10–55VDC |
| Efficiency | Up to 90% |
| Power Factor | ≥0.95 |
| THD | <15% |
| Inrush Current | <40A |
| Operating Temperature | -20°C to +50°C |
| Case Temperature (Tc) | 90°C max |
| Output Protection | Short circuit, overload, thermal |
| Dimming Control | 0-10V |
| Dimming Range | 1% – 100% |
| Advanced Features | Wide programmable current range |
| Enclosure Rating | IP20 |
| Dimensions | ~7.5" x 2.0" x 1.2" |
| Mounting Length | ~7.0" |
| Certifications & Compliance | UL, FCC, RoHS |
| Sound Rating | Class A |
| Warranty | 5 Years |
