eldoLED ECOdrive 1065/S 100W DALI LED Driver
Description
Description
The ECOdrive 100W (EC1065S1) is a high-capacity DALI-2 constant current LED driver engineered for professional architectural lighting. Housed in a robust square metal enclosure with a side-feed configuration, it utilizes eldoLED’s signature HydraDrive technology to provide standard fixtures with exceptionally smooth, flicker-free dimming down to 1%. This driver is the industry standard for large-scale applications requiring high power and precise light control.
Key Features
-
Natural Dimming: High-performance dimming to 1% with smooth brightness transitions and adaptable dimming curves.
-
IoT & Connectivity: LEDcode2 interface connects to digital accessories and supports location-based IoT applications through wired or wireless peripheral devices.
-
Camera Compatibility: Proven Hybrid HydraDrive technology ensures flicker-free performance in TV studios and security camera environments.
-
Symbiosis Technology: Seamless interoperability with various LED modules, sensors, and intelligent in-luminaire devices.
-
Precision Tuning: Fully programmable output current and configurable minimum dimming levels to suit any specific application.
Technical Specifications
| Attribute | Specification |
| Driver Type | Constant Current |
| Output Channels | 2 (UL Class 2) |
| Max Output Power | 100W |
| Programmable Current | 150 – 1400mA (1mA increments) |
| Output Voltage Range | 2 – 55VDC |
| Input Voltage (AC) | 120 – 277V (UL) / 120 – 250V (ENEC) |
| Input Voltage (DC) | 120 – 250V |
| Control Protocol | DALI-2 Device Type 6 / LEDcode2 |
| Control Channels | 1 |
Electrical & Performance Data
-
Universal Input: Optimized for global use with a wide AC/DC input range.
-
Power Quality: Low inrush current and Total Harmonic Distortion (THD) with a high power factor.
-
Efficiency: Designed for high efficiency to minimize heat buildup in 100W installations.
Mechanical Details
-
Form Factor: Square Metal / Side Feed
-
Dimensions (LxWxH): 230 x 80 x 30mm (9.06" x 3.15" x 1.18")
-
Weight: 912.5g (32.19 oz)
Support & Ordering
-
Customization: Fine-tune your driver for any application using eldoLED programming tools.
-
Direct Assistance: For technical questions or order support, call 407-777-0942.
Specifications
Specifications
| Attribute | Specification |
|---|---|
| Driver Type | Constant Current |
| Output Channels | 2 (UL Class 2) |
| Max Output Power | 100 W |
| Programmable Current | 150–1400 mA (1 mA increments) |
| Output Voltage Range | 2–55 VDC |
| Input Voltage (AC) | 120–277 V (UL) / 120–250 V (ENEC) |
| Input Voltage (DC) | 120–250 V |
| Control Protocol | DALI-2 Device Type 6 / LEDcode2 |
| Control Channels | 1 |
