eldoLED ECOdrive 15D Constant-Current DMX LED Driver
Description
Description
The eldoLED ECOdrive 15D is a 15W DMX-compatible LED driver with four LED outputs. Designed for high-performance color and dimming control, it offers smooth fades and precise brightness adjustment via its intuitive 3-button user interface with display. Whether in architectural lighting or fast-paced entertainment environments, the ECOdrive 15D provides programmable currents, HydraDrive smooth dimming, and robust thermal management for consistent performance.
Highlights:
-
ECOdrive DC, 15W, DMX
-
4 control channels, constant current
-
4 × LED outputs
-
Plastic long form factor
-
HydraDrive technology for smooth color fades and dimming
-
Configurable on-the-fly via user interface or DMX
Features:
-
Four LED outputs powered by a single current source
-
Smooth dimming and color transitions with HydraDrive
-
Programmable current range: 200–500 mA
-
NTC interface for thermal protection
-
High efficiency up to 95%
-
Dynamic response tuning for both slow architectural fades and fast entertainment video content
Specifications
Specifications
| Attribute | Specification |
|---|---|
| Driver Type | Constant Current |
| LED Outputs | 4 (UL Class 2) |
| Max LED Output Power | 15 W |
| Programmable LED Current | 200–500 mA (50 mA steps via driver UI, 25 mA steps via DMX/FluxTool) |
| LED Output Voltage Range | 11–31 V (Vf LEDs < Vsup-1V) |
| Input Voltage (AC) | 120–250 V (ENEC), 120–277 V (UL) |
| Input Voltage (DC) | 12–32 V |
| Control Protocol | DMX |
| Control Channels | 4 |
| Dimensions (L×W×H) | 153 × 50 × 23 mm (6.02 × 1.97 × 0.91 in) |
| Weight | 128.5 g |
